• A high-quality stainless steel beverage filling machine by Redwood Stainless Systems. The advanced automated system features multiple filling heads, a glass enclosure for hygiene, and a digital control panel for precise operation. The sleek, industrial design is built for efficiency in brewery and beverage production.
  • Counter pressure filling heads close-up
  • Counter pressure filling heads close-up
  • Can seaming mechanism detail
  • Stainless steel frame and safety door
  • Allen-Bradley PLC control panel interface
  • Can seaming mechanism detail
  • Can seaming mechanism detail
1 8

Redwood Stainless Systems

Elm 400CPM Counter Pressure Canning Line

Elm 400CPM Counter Pressure Canning Line

• Capacity: 400 CPM (12oz)

• Counter pressure filling

• Low D.O. measurement with exhaust oxygen device

• Automatic bowl lifting device with SEW Reducer, Encoder, and Braking function

• SKF auto. lubrication system

• Safety Protection: Stainless steel frame,Tempered glass door,360º Inlet and outlet direction

Request Quote Financing Available
View full details

The Elm 400CPM Counter Pressure Canning Line is designed for breweries and carbonated beverage producers that need reliable in-house canning with consistent fill quality, stable carbonation, and lower oxygen pickup. With throughput up to 400 cans per minute, it gives production teams a practical packaging solution for large craft breweries, contract brewers, and high-volume beverage packaging facilities.

Using isobaric counter-pressure filling, the system equalizes pressure between the product tank and the can before filling. This helps control foaming, preserve carbonation, reduce product loss, and support more consistent package quality for beer, cider, kombucha, hard seltzer, sparkling water, soda, RTD beverages, and similar carbonated drinks.

The Elm 400CPM line supports an integrated filling and seaming workflow, operator-focused controls, sanitary production practices, and repeatable day-to-day operation. It is a strong fit for teams that need ultra-high-speed packaging for larger distribution programs without losing control over product quality or packaging schedules.

For producers upgrading from smaller equipment, mobile canning, or lower-speed packaging systems, Elm provides a scalable path toward controlled in-house canning, better production planning, and more consistent finished cans.

Key Benefits

- Up to 400 cans per minute for large-scale beverage production

- Counter-pressure filling helps reduce CO₂ breakout, foaming, and oxygen pickup

- Designed for high-throughput in-house canning operations

- Integrated filling and seaming workflow for production efficiency

- Suitable for beer, cider, hard seltzer, sparkling water, soda, kombucha, and RTDs

- Built for consistent package quality across long production runs

- Strong fit for producers expanding into larger distribution volumes

Q1: Who is the Elm 400CPM canning line best suited for?

A: It is best suited for breweries and beverage producers that need ultra-high-speed packaging for larger distribution programs, consistent fill quality, and a controlled in-house packaging workflow.

Q2: How fast can the Elm 400CPM run?

A: The Elm 400CPM is designed for up to 400 cans per minute, depending on product conditions, carbonation level, can format, and final configuration.

Q3: What filling method does this canning line use?

A: It uses isobaric counter-pressure filling, which pressurizes the can before filling to help reduce foaming, preserve carbonation, and lower oxygen pickup.

Q4: Why is counter-pressure filling important for carbonated beverages?

A: Counter-pressure filling helps control CO₂ breakout and foam during filling. This supports more consistent fills, better carbonation retention, reduced product loss, and improved package quality.

Q5: What beverages can be packaged on this system?

A: It is suitable for beer, cider, kombucha, hard seltzer, sparkling water, soda, RTD cocktails, and other carbonated beverage applications.

Q6: Can it support different can sizes?

A: Yes. Changeover options are available for common beverage can formats such as 12 oz, 16 oz, and 500 mL, depending on the final setup.

Q7: Is this system suitable for low-DO packaging goals?

A: Yes. The counter-pressure filling process is designed to support lower dissolved oxygen pickup compared with uncontrolled open filling.

Q8: What maintenance should operators expect?

A: Typical maintenance includes routine inspection of seals, lubrication of moving parts, CO₂ system checks, and cleaning procedures based on the production schedule.

Q9: Is installation and training available?

A: Yes. Redwood can support installation, operator training, spare parts planning, and ongoing technical support based on the final project scope.

Q10: When should a producer choose the Elm 400CPM instead of another speed?

A: Choose the Elm 400CPM when your expected canning volume, labor plan, and production schedule match large craft breweries, contract brewers, and high-volume beverage packaging facilities. Smaller or larger Redwood systems may be a better fit depending on your growth stage.
