Overview
Isobaric Filling System:
- Precise CO2 Control: Utilizes isobaric filling technology, introducing carbon dioxide at the same pressure as the beer tank during the filling process.
- Consistent Pressure Maintenance: Ensures even replacement of gas inside the cans, maintaining consistent pressure which reduces CO2 loss and foam formation.
- Enhanced Product Quality: Achieves a higher alcohol content with a lower oxygen increase, preserving taste and extending shelf life.
Pre-Filling and Sealing Enhancements:
- Oxygen Displacement: The machine pre-blows CO2 into the cans to fully displace oxygen, significantly reducing oxygen levels.
- Foaming Device: Installed prior to capping to eliminate air at the top of the can, enhancing the sealing process.
- Adaptive Capping Mechanism: Equipped with devices for various lid types, facilitating easy switching to adapt to different production needs.
Benefits:
- Ensure the integrity of each canned beverage with a system designed to minimize oxygen exposure and maintain carbonation.
- The seamless integration of filling and sealing processes optimizes efficiency and enhances beverage quality.
- Tailored to support diverse cap types, the system allows for flexible production changes under varying conditions.
Technical
- Production Capacity: 200-400 cans/hour
- Working Pressure (MPa): 0.2-0.4 MPa
- Operating Consumption (kg/h): 800kg/h
- Number of Filling Valves: 1 head
- Number of Seaming Heads: 1 head
- Filling Temperature: 0-4°C
- Maximum CO2 Content: 5.5g/L
- Filling Pressure (CO2): 0.15～0.4 MPa
- Filling Method: Isobaric CO2 replacement
- Bottle Conveyor Height: 1150～1300mm
- Liquid Level Control: Electronic flow meter
- Oxygen Removal Device: Capable of CO2 replacement, high temperature, and high-pressure foaming
- Compressed Air Consumption: 2 m³/h (at 0.3 MPa)
- Sterile Air Consumption: 6 m³/h (at 0.4 MPa)
- Consumption (at 0.6 MPa): 30KG/ton of beer
- Foaming Water Consumption: 2 L/h
- Suitable Bottle Type: Cans
- Cap Size: 202 Easy-Open Lid
- Cap Feeding Method: Automatic
- Seaming Head: Up-and-down seaming (Easy-Open Lid)
- Filling Platform: Hygienic design, easy to clean
- Bearing Brand: SKF/NSK
- Seal Brand: STERING
- Pneumatic Components: CHELIC
- PLC: Siemens
- Frequency Converter: Danfoss
- Relays: Schneider
- High-Pressure Foaming Pump: Stainless steel centrifugal pump
- Equipment Dimensions: 900mm (L) x 600mm (W) x 600mm (H)
- Shipping Weight: 200kg
- Main Motor Power: 2KW (Variable Frequency Speed Control)
- Control Voltage: DC 24V
- Operating Voltage: AC 220V
- Control Power Cabinet: Stainless steel integrated control cabinet
